What is the hourly flow rate of TVC gas turbine flowmeter g1000?

G1000 should have a maximum flow rate of 1600 cubic meters per hour and a minimum flow rate of 80 cubic meters per hour, with a range ratio of 20:1. Elster Stromets TVC is a turbine flowmeter with an integrated correction instrument. The correction instrument displays the actual reading and flow rate of the flowmeter. Through built-in sensors, the flow meter can also calculate the flow rate under standard conditions based on operating pressure and temperature. In addition, when performing volume conversion, Qing Zhengjin also considers the compression coefficient of the gas. The compression coefficient of various gases can be set to a fixed value or calculated according to various calculation formulas. The TVC gas turbine flowmeter has the characteristics of long-term stability, high accuracy, and reliable use in a stable state. Due to the Elster Stromet patented measuring core, maintenance service time is saved, and TVC can replace the measuring core and adjust the measuring range on site. The measuring core of the turbine flowmeter is supported by an O-ring and is not affected by stress, therefore, it is not affected by the flowmeter casing or environmental conditions such as temperature. Working principle: Gas flows through the flow meter to drive the turbine blades to rotate. The number of revolutions of the impeller is directly proportional to the volume of gas passing through the turbine flowmeter. A specially designed patented guide frame is installed at the inlet of the flowmeter to accelerate the airflow entering the flowmeter. The design of the guide frame can eliminate any potential fluid disturbances, such as eddies or asymmetric flow

s. As the flow rate increases, the driving force on the turbine blades also increases. Ensure high-precision measurement of the flowmeter within the allowable error range, even at small flow rates. The airflow acting on the turbine blades is axial, and the turbine is installed on the main drive shaft, which is equipped with high-strength ball bearings. After the rotation of the turbine blades is reduced by the gear set, the working condition flow pulse signal is directly uploaded to the TVC integrated correction instrument through the magnetic coupling mechanism installed on the worm gear. The temperature and pressure of the gas being measured in Qingyou are also accurately measured by the built-in high-precision temperature and pressure sensors and uploaded to the integrated correction instrument for standard condition flow calculation. After the gas passes through the turbine blades, the pressure is restored in the outlet channel, and the channel design ensures the optimization of the flow state. Sorry, the attachment uploaded by the respondent is no longer valid

2. Model of turbine flowmeter

Model specifications nominal diameter dn (mm) flow range (m3/h) working pressure (mpa) installation form lmm g d number of holes lw-4 4 0.04-0.25 1.62.54.06.310.015.020.025.0 thread (clamp) 394 (50) r3/8 lw-6 6 0.1-0.6 thread (clamp) 430 (50) r3/8 lw-10 10 0.2-1.2 thread (clamp) 556 (50) r3/8 lw-15 15 0.6-6 thread (clamp) 75 (55) g1 lw-20 20 0.7-7 thread (clamp) 85 g1 lw-25 25 1-10 thread (clamp) 100 (60) gr1/4 selling cluster bridge lw-32 32 1.5-15 clamp 70 lw-40 40 2-20 thread (clamp) 140 (70) g2 lw-50 50 4-40 Threads (clamp) 150 (70), diameter 150, diameter 18, diameter 4, weight 65, height 75, diameter 75, diamet
