Price of metal tube float flowmeter

『Price of metal tube float flowmeter』Related information(clamp on meter|electromagnetic meter|venturi meterrotameter|orifice meter|ultrasonic flow meter|mass flow meter|coriolis mass flow meter|coriolis flow meter|magnetic flow meter|magmeter flow meter|magflow flow meter|mag meter flow meter|electromagnetic flow meter|vortex flow meter|turbine flow meter|thermal mass flow meter|thermal flow meter|rotameter flow meter)

1. Measurement of metal tube float flowmeter

1. Sturdy all metal structure design type float flowmeter

2. Measuring tube indicator designed with independent concept

3. Stainless steel, Hastelloy, titanium materials can be selected.

PTFE material measurement system

4. Low pressure loss design

5. Short stroke and small structure with beam gauges, total instrument height of 250

6. Magnetic coupling structure ensures data transmission and more stable signal attenuation

7. Insulation or heat tracing jacket

8. Vertical, horizontal, and various installation methods are more suitable for different usage scenarios of Qiaozhen

9. Suitable for small caliber and low flow medium flow measurement, reliable operation, low maintenance, long service life 1

1. Low requirements for straight pipe sections 1

2. Wide flow ratio 10:11

3. Dual row large liquid crystal display, optional on-site instantaneous/cumulative flow display, can be backlit 1

4. Single axis sensitive indication 1

5. Non contact magnetic coupling transmission 1

6. All metal structure, suitable for high temperature, high pressure and strong corrosive media 1

7 Can be used in flammable and explosive hazardous environments 1

8. Two wire system, battery, AC power supply 1

9. Multi parameter calibration function 20. With data recovery, data backup, and power failure protection functions

2. River Doppler flowmeter manufacturer

3. Can metal tube float flowmeter measure different media

Metal tube float flowmeter can measure the instantaneous flow and cumulative flow of gases, liquids, including corrosive acid, alkali, and macro salt solu

Price of metal tube float flowmeter
tions. In special provinces, it is preferred to choose low flow or pure mechanical type when inconvenient power supply is needed. Metal float flowmeter is mostly installed vertically with bottom in and top out type, or can be installed horizontally. Installation, the price is higher. Let me show you a sample. This is an intelligent device for measuring corrosive liquid explosion resistance. It can measure both gases and liquids without impurities. This is a horizontal installation measuring nitrogen gas, with a pure mechanical display of instantaneous flow rate.

4. Structure principle of metal tube float flowmeter

Metal tube float flowmeter is a commonly used flow measurement instrument, and its structure principle is as follows: Working principle: The float of the metal tube float flowmeter is placed in the measuring tube, and when the fluid flows through the measuring tube, the float will be subjected to the force of the fluid.

. As the flow rate changes, the float will move up and down inside the measuring tube. When the float moves to a certain position, the buoyancy it receives reaches an equilibrium state with its own gravity. At this point, a circulation gap will be formed between the float and the orifice plate (or cone tube), and the area of this gap will remain constant. And the annular gap area is directly proportional to the rising height of the float, that is, the position of the float rising in the measuring tube can represent the size of the flow rate. In order to transmit the position information of the float to indicate the flow value, a magnet is installed inside the float. The change in float position is transmitted to the external indicator through an internal magnet, allowing the in
