1. Share the wiring method of the two-wire system for vortex flowmeter?

For the two-wire wiring method of the vortex flowmeter, please refer to the attached diagram. When you open the junction box, you can see a row of wiring terminals on the green circuit board. The first group is connected to the positive+24V power line, and the second group is connected to the current output signal accompanying wire. The two-wire wiring method here is 24V+and current I+. If this is a combination wiring, that is, the wiring method for the 4-20mA output of the two-wire system, be sure to pay special attention when wiring and do not connect it incorrectly.

2. Pipeline Flow Meter

3.7F2C80-WM19/0 Flow Meter 7F2C80-ABCCAAAD2SKA1+Z1 Endhaus

7F2C80-WM19/0 Flow Meter (model 7F2C80-ABCCAAAD2SKA1+Z1, Endhaus) is a multivariable vortex flow meter based on Prowirl F technology, suitable for measuring wet steam, gas, and liquid, with high accuracy, high safety, and long-term stability.

1. Core application areas Wet steam measurement: specially designed for wet steam/saturated steam/superheated steam, with a diameter range of DN25~DN300 (1~12 inches), covering common pipe diameters in industrial steam systems.

. Gas and liquid measurement: Supports low flow rate gas, liquid, and low-temperature medium measurement, suitable for energy management, chemical processes, and other scenarios. Dangerous area application: With explosion-proof certification (such as ATEX, IECEx), it can operate safely in explosive environments.

2. Technical Features and Advantages High Precision and Calibration Technology PremiumCal Calibration Options: Ensure measurement accuracy at low flow rates (such as gases, vapors, li

quids) to meet the reliability requirements of the factory.

. Compliant with ISO 12764 standard: internationally certified measurement technology to ensure data accuracy. Low Reynolds number adaptability: Even if the Reynolds number of the medium is as low as Re 10000, the accuracy is not affected, making it suitable for low flow rates or viscous fluids. Economic efficiency of two-wire circuit power supply design: The Prowirl F 200 model adopts a two-wire power supply, simplifying installation and reducing wiring costs. System integration: It can seamlessly integrate with existing control systems without the need for additional power or cumbersome configuration. Heartbeat Technology for Safety and Reliability: Real time self verification function, continuously monitoring instrument status to ensure process safety. No need to open the lid operation, avoiding the risk of human intervention. Dual chamber casing: sturdy and durable, suitable for harsh industrial environments. International certification: Through SIL (Safety Integrity Level) and explosion-proof certification, it meets the requirements of high-risk scenarios. Multi functional measurement and display of multivariate detection: Equipped with temperature and pressure sensors, it can simultaneously output parameters such as mass flow rate, volume flow rate, temperature, and pressure. Data transmission function: The display unit supports digital communication, facilitating remote monitoring and data analysis. Long term stability and maintenance convenience of capacitive sensors: drift free design ensures long-term stability of measurement and reduces calibration frequency. Independent wiring chamber: simplifies the wiring process and supports quick maintenance a
