Coriolis Mass Flow Meter Animation: Visual Vibrating Fluid Loop Overviews
Quick Answer: A Coriolis mass flow meter animation shows one or two tubes vibrating inside a sealed sensor housing. The visual loop view helps engineers understand phase shift, fluid density effect, and direct mass flow output. Silver Instruments supplies these meters for oil and gas, chemical, food, and water sites across Southeast Asia, Oceania, Latin America, Africa, and the Middle East.
What the Animation Actually Shows
A Coriolis meter animation starts with a U-shaped or triangular tube loop. A drive coil pushes the tube at its natural frequency. Two pickup sensors sit on the inlet and outlet legs. In a no flow condition the pickup signals match. When process fluid moves through the loop, the tube legs twist. This twist creates a time difference between the two sensor signals. The meter converts that time difference to mass flow. This is not a volumetric calculation. The output is direct kg/h or lb/min. Because the tube vibrates constantly, the animation also shows how the frequency changes with fluid density. Denser fluids lower the vibration frequency. Operators can use that signal for density readout or concentration monitoring. The animation often highlights a PT100 sensor embedded in the tube wall for temperature compensation.
Why the Visual Loop Matters for Sizing and Installation
A factory test animation removes much of the guesswork. Engineers see how the meter handles two phase flow, gas slugs, or viscous product. For example, a customer in Vietnam asked us about a Coriolis meter for fish paste at 40,000 cP. The animation helped them see why a straight tube design was not the best fit. We recommended a bent tube DN25 model with high drive gain. On site the meter held accuracy at 0.2 percent of rate. Most engineers skip this part. They look only at line size and pressure rating. But the live loop view shows stress limits, zero stability, and minimum flow thresholds.
Key Parameters to Specify for a Quote
Send us your pressure (bar), temperature (°C), pipe size (DN), and flow range. For Coriolis meters we also need viscosity (cP), density range (kg/m3 or g/cm3), and required accuracy. A DN15 Silver Instruments CMF meter can read low flows from 0.1 kg/h to 600 kg/h depending on the model. A DN50 line can handle 0 to 36,000 kg/h. Output options include 4-20 mA HART, RS485 Modbus, and pulse. Hazardous area certifications cover ATEX Zone 1 or IECEx. If you measure LPG or light chemicals, tell us the vapor pressure at working temperature. That single data point changes the sensor selection.
Common Application Notes From Customer Sites
A paint manufacturer in Southeast Asia uses a DN15 Coriolis meter to dose resin at 3,000 cP. They had a volumetric oval gear meter before. The resin changed density from batch to batch. Mass flow was unstable. The Coriolis meter gave them direct kg/h control. A desalination plant in the Middle East uses a DN80 Coriolis meter on brine concentrate with 4-20 mA HART output. The meter reads density at 1.18
Animation and Training for Plant Teams
We often send a short visual loop animation file with the quotation. A maintenance supervisor can watch the tube movement and sensor signals before installation. The animation shows the inlet and outlet legs bending. It marks the drive coil and pickup sensors. In practice the meter body does not move much. The displacement is only a few microns at 80 to 110 Hz. But a visual overview trains technicians faster than a 30 page manual. Here is the thing. An animation does not change the measurement principle. It just shows the phase shift. Your team can also contact us for a live online walkthrough of a DN25 meter on our test bench.
Recommended Silver Instruments Models for Coriolis Animation Reviews
We keep a standard range of Coriolis mass flow meters from DN15 to DN100. The small DN15 and DN25 models suit chemical dosing, flavors, and pilot plants. The DN40 and DN50 models cover food, beverage, and fuel oil transfer. The DN80 and DN100 models handle bulk loading, brine, and crude oil blending. All units include a local display and a stainless steel sensor housing. The electronics support 4-20 mA HART, RS485 Modbus, and a pulse output for remote totalization. Inline density and temperature signals are standard. You can see the vibrating loop overview in our quotation drawings before purchase.
Frequently Asked Questions
What does the Coriolis meter animation show in simple terms?
It shows how two sensor signals shift when fluid flows through a vibrating tube. The time difference is proportional to mass flow.
Can this meter measure gas and liquid?
Yes. A Coriolis mass flow meter measures liquids and gases directly by mass. You need to tell us the density range and pressure so we can select the right sensor.
What is the minimum flow for a DN15 model?
A DN15 Silver Instruments Coriolis meter can read from around 0.1 kg/h depending on fluid density and viscosity. Very low flows need a smaller tube and stable zero calibration.
Do you offer ATEX Zone 1 versions?
Yes. We supply ATEX Zone 1 and IECEx certified models. Tell us the gas group and temperature class when you send the inquiry.
What information do you need for a price quote?
We need pressure (bar), temperature (°C), pipe size (DN), flow range, viscosity (cP), and density. Add the hazardous area zone if the meter goes into an Ex location.
Send us your pressure (bar), temperature (°C), pipe size (DN), and flow range. Add viscosity (cP), density (kg/m3), and hazardous area zone if known. We will return a model recommendation and price quote within one working day.
